Description
Electrical Characteristics
Voltage Rating: 300V RMS
Temperature Rating: 75°C
Conductor: 22 AWG Stranded Bare Copper (7/0.24mm)
Insulation: Polyvinyl Chloride (PVC), 1.10mm diameter
Physical Characteristics
Jacket Material: Polyvinyl Chloride (PVC)
Jacket Thickness: 0.45mm
Overall Diameter: 3.60mm
Rip Cord: Yes
Conductor Count: 4 (Green, Red, Black, White)
Jacket Colors: Grey, White
Features & Applications
Class 2 Power Limited Circuit Cable and Communications Cable for General Purpose Application. ETL Listed. Suitable for security system installations, CCTV, access control, and low-voltage communication applications.
Construction
Cable Marking: 22AWG 4 COND STRANDED XXXX CMR FT4 C(ETL)US ****FT
Additional Information
Package: 1000FT / REELEX II Pull Box. Riser (CMR) rated for vertical runs between floors through riser shafts. Stranded bare copper conductors provide flexibility for pulling through conduit and tight spaces.
Additional Info & Specs
| Conductor | Bare Copper |
| Number of Conductors | 7 |
| AWG | 22 |
| Conductor Diameter | 7/0.24mm |
| Insulation Material | PVC |
| Insulation Diameter | 1.10mm |
| Insulation Colors | Red, Black, White, Green |
| Jacket Material | PVC |
| Jacket Thickness | 0.45mm |
| Overall Diameter | 3.60mm |
| Rip Cord | Yes |
| Voltage Rating | 300V RMS |
| Temperature Rating | 75°C |
| Package | 1000ft / REELEX II Pull Box |
| Rating | CMR / FT4 |
