trueCABLE Cat6 Riser UTP Ethernet Cable - 1000ft
The trueCABLE 6ECMRBLU_1Kbx is a 1000ft Cat6 riser-rated unshielded twisted pair (U/UTP) bulk Ethernet cable engineered for permanent in-wall and riser backbone installations. Built with 23 AWG solid bare copper conductors and a CMR-rated PVC jacket, it delivers verified performance up to 550 MHz with headroom above the ANSI/TIA 568.2-D Cat6 requirement.
Built for Riser and In-Wall Pathways
The CMR (Communications Riser) jacket rating permits installation in vertical riser shafts and between floors in commercial and residential buildings, where plenum-rated cable is not mandated. A nylon ripcord and center spline simplify jacket stripping and help maintain pair geometry and crosstalk performance throughout the pull.
Power over Ethernet Ready
Solid bare copper conductors support IEEE 802.3af (PoE), 802.3at (PoE+), and 802.3bt (4PPoE) power delivery, making this cable suitable for access points, IP cameras, VoIP handsets, and PoE lighting runs where both data and power travel over a single cable.
Verified Performance
Every reel is tested to 550 MHz and carries UL-444, cETLus, RoHS-3, and ETL Intertek listings, with compliance to ANSI/TIA 568.2-D and ISO/IEC 11801. The 100 ± 15 ohm impedance across the full 1.0-550 MHz range keeps return loss and signal integrity predictable across long horizontal runs.
Installation Notes
Maximum installation tension is 110N (25 lb-ft) and the minimum bend radius is 2.5cm (1.0in). The cable is rated for operation from -40 degrees C to 75 degrees C, with an installation temperature range of -20 degrees C to 75 degrees C. Maximum operating voltage is 300V.
Additional Info & Specs
| Category | Cat6 |
| Part Number | 6ECMRBLU_1Kbx |
| Conductor Gauge | 23 AWG |
| Conductor Material | Solid Bare Copper |
| Conductor Count | 4 Twisted Pairs |
| Shielding | U/UTP (Unshielded) |
| Jacket Material | PVC |
| Jacket Rating | CMR (Riser) |
| Max Frequency | 550 MHz |
| Impedance | 100 +/- 15 Ohm (1.0 - 550 MHz) |
| Outer Diameter | 5.90 mm (+/- 0.2 mm) |
| NVP | 68.2 |
| Max Operating Voltage | 300V |
| Max Installation Tension | 110N / 25 lb-ft |
| Min Bend Radius | 2.5 cm / 1.0 in |
| Operating Temperature | -40 C to 75 C (-40 F to 167 F) |
| Installation Temperature | -20 C to 75 C (-4 F to 167 F) |
| Ripcord | Nylon |
| Spline | Yes |
| Length | 1000 ft |
| PoE Support | IEEE 802.3af / 802.3at / 802.3bt (4PPoE) |
| Standards | ANSI/TIA 568.2-D, ISO/IEC 11801 |
| Certifications | UL-444, cETLus, RoHS-3, ETL Intertek |
