Superior Essex 6A-246-2B Cat6A Plenum UTP 23AWG UL Listed 1000ft Blue Ethernet Cable

Superior Essex 6A-246-2B Cat6A Plenum UTP 23AWG Solid Copper 1000ft Ethernet Cable

The Superior Essex 6A-246-2B is a premium 23 AWG solid annealed copper Cat6A plenum (CMP) unshielded twisted pair cable engineered for 10GBASE-T Ethernet networks. Built with a proprietary core wrap and cross-web separator, this cable delivers guaranteed 1 dB AXT margin and is tested to 650 MHz — providing substantial headroom beyond the Cat6A standard. UL Listed and verified; it meets ANSI/TIA-568.2-E compliance for enterprise, datacenter, LAN, and residential installations.

Construction & Design

Each of the 4 pairs features FEP thermoplastic insulation with Superior Essex's ColorTip circuit identification system for easy conductor matching even in low-light environments. The flame retardant LSPVC jacket is rated CMP (plenum) with low-smoke characteristics, making it suitable for air-handling spaces per NEC (NFPA 70) Article 800. The cable includes a proprietary core wrap that assures excellent alien crosstalk (AXT) performance without the need for grounding or bonding.

Performance & Compliance

• ANSI/TIA-568.2-E Compliant
• UL Verified CAT6A
• UL Listed CMP-LP (0.5)
• c(UL) Listed CMP
• UL 444, CSA C22.2 No.214-08, UL 1666
• Tested to 650 MHz
• Guaranteed 1 dB AXT margin
• Characteristic Impedance: 100 ± 15 Ohms
• NVP: 71%

Applications

• 10BASE-T through 10GBASE-T Ethernet
• Power over Ethernet (PoE) — IEEE 802.3bt Type 1 to 4
• ATM and token ring
• HDBaseT Class A and B
• Backward compatible to legacy protocols

Physical Specifications

Sustainability

This cable is UL Certified with an Environmental Product Declaration (EPD), Health Product Declaration (HPD), and Multi-Attribute Certification by Green Circle Certified, LLC — contributing toward LEED credits. Made in the USA. RoHS and REACH compliant.
