Description
The General Cable 7131107 CAT6 Plenum Ethernet Cable delivers professional-grade networking performance for commercial and industrial installations. This 1000ft black UTP cable features 23AWG solid bare copper conductors and meets stringent plenum fire safety requirements. Engineered with GenSPEED technology, it provides reliable data transmission up to 250 MHz with superior crosstalk protection and consistent electrical performance.
Product Specifications
- Cable Type: Category 6 UTP (Unshielded Twisted Pair)
- Conductor: 23AWG solid bare annealed copper
- Length: 1000 feet
- Color: Black
- Fire Rating: CMP (Plenum) - NFPA 262 compliant
- Jacket Material: Low-smoke, flame-retardant PVC
- Cable Diameter: 0.205 inches
- Weight: 25 lbs per 1000 feet
- Part Number: 7131107
Key Features & Benefits
- Unique Separator Design: Engineered divider ensures consistent electrical performance and reduces crosstalk
- TRU-Mark Print Legend: Sequential footage markings from 1000' to 0' for easy installation tracking
- Third-Party Verified: Guaranteed performance backed by independent testing
- Made in USA: Quality manufacturing with domestic production
- RoHS Compliant: Environmentally responsible construction meeting EU directive 2011/65/EU
Applications & Uses
Network Applications:
- Gigabit Ethernet (1000BASE-T)
- Fast Ethernet (100BASE-TX)
- 10BASE-T networks
- Power over Ethernet (PoE, PoE+, PoE++)
Specialized Uses:
- Building automation systems
- Digital video transmission
- Token Ring and ATM networks
- Broadband and baseband analog video
Construction Details
Wire Configuration: Four twisted pairs with color-coded insulation:
- Pair 1: Blue-White/Blue
- Pair 2: Orange-White/Orange
- Pair 3: Green-White/Green
- Pair 4: Brown-White/Brown
Safety Features: FEP and polyolefin insulation with integrated rip cord for easy jacket removal. The plenum-rated jacket provides low-smoke characteristics essential for air handling spaces.
Performance Specifications
- Frequency Range: Up to 250 MHz
- Characteristic Impedance: 100 ± 15 ohms
- DC Resistance: 9.38 ohms/100m maximum
- Velocity of Propagation: 70% speed of light
- Operating Temperature: -20°C to +75°C
- Installation Temperature: 0°C to +60°C
- Minimum Bend Radius: 1.0 inch
- Maximum Pulling Force: 32 lbs
Standards Compliance
Meets or exceeds ANSI/TIA 568.2-D, UL 444, ICEA S-116-732, and ISO/IEC 11801 Ed. 2.0 Class E standards. UL Listed and ETL Verified for quality assurance.
Additional Info & Specs
| Color | Black |
|---|---|
| Product Type | Ethernet Cable |
| Condition | New |
| Brand | General Cable -GenSPEED |
| Package | Box - Pull-Pac II |
| Category | 6 |
| Spaces | Plenum |
| Gauge | 23 AWG |
| Jacket | Plenum-Rated |
| Insulation Material | FEP - Polyolefin |
| No. of Pairs | 4 Twisted |
| Shielding | Unshielded |
| Conductor | Solid |
| Conductor Material | Bare Copper |
| Certification Standards | UL Listed, RoHS, TIA, ETL Listed |
